Service Guide N5230-90024 5-25
PNA Series Microwave Network Analyzers Theory of Operation
N5230C Digital Processing and Digital Control Group Operation
A41 Hard Disk Drive
The hard disk drive assembly (HDDA) is an integrated development environment (IDE) data storage device
which is connected directly to the A15 CPU board. The full operating system and firmware for the network
analyzer is stored on the A41 hard disk drive.
USB Hub
The rear-panel mounted, internal USB hub provides four additional USB ports for connection of external USB
compatible devices.
Parallel A 36-pin, mini-D, 1284-C connector that provides connection to printers or any other parallel
port peripheral.
LAN A standard 8-pin, 10/100BaseT, Ethernet connection. It auto selects between the two data
rates.
Display (VGA) A 15-pin, female, D-sub connector that provides a video output of the analyzer display that
can be viewed on an external VGA monitor.
