Service Guide N5230-90024 6-47
PNA Series Microwave Network Analyzers Replaceable Parts
N5230C Replaceable Parts Listings
Fuses
Rear Panel Bias Input Fuse Port 1, Port 2 (0.5 A, 125 V) (Option UNL) 2110-0046
ESD Supplies
Adjustable antistatic wrist strap 9300-1367
Antistatic wrist strap grounding cord (5 foot length) 9300-0980
Static control table mat and earth ground wire 9300-0797
ESD heel strap 9300-1126
EMI/RFI Shielding Accessories
7 mm ferrite bead for serial cable 9170-1793
9 mm ferrite bead for parallel port 9170-1702
Upgrade Kits
Time Domain
(Option 010)
N5230CU-010
Frequency Offset Mode
(Option 080)
N5230CU-080
Add built-in performance test software for Agilent inclusive calibration perpetual license
(Option897)
N5230CU-897
Add built-in performance test software for standards compliant calibration perpetual license
(Option898)
N5230CU-898
20 GHz Standard Test Set to Configurable Test Set with Extended Power Range (serial prefix
MY4500 and below) (Option 220 to 225)
N5230CU-921
20 GHz Standard Test Set to Configurable Test Set with Extended Power Range (serial prefix
MY4640 and above) (Option 220 to 225)
N5230CU-922
40 GHz Standard Test Set to Configurable Test Set with Extended Power Range
(Option 420 to 425)
N5230CU-941
50 GHz Standard Test Set to Configurable Test Set with Extended Power Range
(Option 520 to 525)
N5230CU-941
Frequency Extension, 20 to 40 GHz Standard Test Set
(Option 220 to 420)
N5230CU-971
Frequency Extension, 20 to 40 GHz Configurable Test Set with Extended Power Range (Option
225 to 425)
N5230CU-973
Frequency Extension, 40 to 50 GHz Standard Test Set
(Option 420 to 520)
N5230CU-990
Frequency Extension, 40 to 50 GHz Configurable Test Set with Extended Power Range
(Option 425 to 525)
N5230CU-990
USB Accessories
Mouse 1150-7799
Table 6-3 Part Numbers for Miscellaneous Parts and Accessories (Continued)
Description
Model or Part
Number
To Next Page
