Service Guide N5230-90024 2-9
PNA Series Microwave Network Analyzers General Product Information
N5230C Required Service Test Equipment
Equipment
a
Critical Specifications
Recommended
Model or Part
Number
Alternate
Model
Number
Use
b
Tools
Extender board N/A E8356-60021 None T
T-8 TORX driver 0.6 N-m (5 in-lb) setting N/A N/A R
T-10 TORX driver
0.5, 0.8, and 1.0 N-m
(4, 7, and 9 in-lb) settings
N/A N/A T, R
T-20 TORX driver 2.4 N-m (21 in-lb) setting N/A N/A T, R
1/4 inch and 5/16 inch open-end
wrench
Thin profile 8710-0510 N/A A, R
5/16 inch, open-end torque wrench
(metric equivalent is 8 mm)
1.1 and 2.4 N-m (10 and 21
in-lb) settings (for semi-rigid
cables)
N/A
N/A T, R
1 inch, open-end torque wrench
(metric equivalent is 26 mm)
8.1 N-m (72 in-lb) setting (for
Port 1 and Port 2 connector
nuts)
N/A N/A R
20 mm, open-end torque wrench
0.9 N-m (8 in-lb) setting (for
Port 1 and Port 2 measurement
connections)
8710-1764
N/A P, A, T
Static Safety Parts
Adjustable antistatic wrist strap N/A 9300-1367 None P, A, T
Antistatic wrist strap grounding
cord (5 foot)
N/A 9300-0980 None P, A, T
Static control table mat and earth
ground wire
N/A 9300-0797 None P, A, T
Miscellaneous
USB flash ROM drive N/A Any None P, A, R
a. Unless specified otherwise, equipment listed is required for all analyzer models.
b. P = Performance tests, A = Adjustments, T = Troubleshooting, R = Repair, V = System verification
