Service Guide N5230-90024 3-3
PNA Series Microwave Network Analyzers Tests and Adjustments
N5230C Information in This Chapter
Performance Tests (Agilent
N7840A Software
Package)
a
A brief summary of each performance test in the Agilent N7840A
software package:
• Source Maximum Power Output Test
• Source Power Linearity Test
• Frequency Accuracy Test
• Trace Noise Test
• Receiver Compression Test
• Noise Floor Test
• Calibration Coefficients Test
• Dynamic Accuracy Test
Page 3-28
Adjustments
Setups and procedures for adjusting your analyzer:
• 10 MHz Frequency Reference Adjustment
• EE Default Adjustment
• LO Power Adjustment
• Source Calibration Adjustment
• Receiver Calibration Adjustment
Page 3-35
a. The Agilent N7840A software package must be purchased separately.
Section Title Summary of Content Start Page
