Service Guide N5230-90024 3-37
PNA Series Microwave Network Analyzers Tests and Adjustments
N5230C Adjustments
8. On the System menu, point to Service, Adjustments, and then click LO Power Adjust.
9. Ensure the GPIB settings are correct.
10. Click Begin Adj, and then follow the instructions as they are displayed.
11. Turn off the analyzer, disconnect the power cable, reconnect the semi-rigid cable W3, and replace the
cover.
