S06C S06C8-9
(6) Insert filter cartridge and
ensure a tight seat.
(7) Install the valve cover on the
filter housing so that the direction
arrow in the marking “OBEN-TOP”
shows upwards. This ensures that
the dust delivery valve is pointing
downwards.
(8) When the indicator field
becomes red (8-20/arrow) push
reset button. The field becomes
clear.
CAUTION
Check all connection pipes and
hoses of the air filter system for
damages before starting the motor.
8.2.9 Replacing the fuel filter
See Engine Operating Instructions.
8.2.10 Change safety
cartridge
CAUTION
The safety cartridge must be chan-
ged after three maintenance peri-
ods, at the latest after two years.
(1) Remove the filter cartridge
(section 8.2.9).
(2) Remove the safety cartridge
(8-21/arrow). Replace the safety
cartridge and the filter cartridge by
new material.
(3) The remaining installation is
performed as described in section
8.2.9 (6) ... (8).
8-9
(6) Sätt tillbaka filterinsatsen.
Se till att den sitter fast ordentligt.
(7) Sätt ventilkåpan på filter-
huset så att riktningspilen med
markeringen „OBEN-TOP“ pekar
uppåt. På så sätt garanteras att
dammavskiljningsventilen pekar
nedåt.
(8) Om underhållsindikatorn
(8-20/pil) visar rött, tryck på
återställningsknappen. Fältet blir då
transparent.
OBSERVERA
Kontrollera att luftfiltersystemets
alla förbindningsrör och -slangar är
intakta innan motorn startas.
8.2.9 Byte av bränslefiltret
Se bruksanvisningen för motorn.
8.2.10 Byte av
skyddsinsatsen
OBSERVERA
Efter en tredje service av filter-
insatsen skall skyddsinsatsen
bytas, dock senast efter två år.
(1) Demontera filterinsatsen
(avsnitt 8.2.9).
(2) Tag ut skyddsinsatsen (8-21/
pil) och ersätt den med en ny. Även
filterinsatsen skall förnyas.
(3) Hur delarna sätts samman
finns beskrivet i 8.2.9 (6)....(8).
(6) Insert filter cartridge and
ensure a tight seat.
(7) Install the valve cover on the
filter housing so that the direction
arrow in the marking “OBEN-TOP”
shows upwards. This ensures that
the dust delivery valve is pointing
downwards.
(8) When the indicator field
becomes red (8-20/arrow) push
reset button. The field becomes
clear.
CAUTION
Check all connection pipes and
hoses of the air filter system for
damages before starting the motor.
8.2.9 Replacing the fuel filter
See Engine Operating Instructions.
8.2.10 Change safety
cartridge
CAUTION
The safety cartridge must be chan-
ged after three maintenance peri-
ods, at the latest after two years.
(1) Remove the filter cartridge
(section 8.2.9).
(2) Remove the safety cartridge
(8-21/arrow). Replace the safety
cartridge and the filter cartridge by
new material.
(3) The remaining installation is
performed as described in section
8.2.9 (6) ... (8).
(6) Sätt tillbaka filterinsatsen.
Se till att den sitter fast ordentligt.
(7) Sätt ventilkåpan på filter-
huset så att riktningspilen med
markeringen OBEN-TOP pekar
uppåt. På så sätt garanteras att
dammavskiljningsventilen pekar
nedåt.
(8) Om underhållsindikatorn
(8-20/pil) visar rött, tryck på
återställningsknappen. Fältet blir då
transparent.
OBSERVERA
Kontrollera att luftfiltersystemets
alla förbindningsrör och -slangar är
intakta innan motorn startas.
8.2.9 Byte av bränslefiltret
Se bruksanvisningen för motorn.
8.2.10 Byte av skyddsinsatsen
OBSERVERA
Efter en tredje service av filter-
insatsen skall skyddsinsatsen
bytas, dock senast efter två år.
(1) Demontera filterinsatsen
(avsnitt 8.2.9).
(2) Tag ut skyddsinsatsen (8-21/
pil) och ersätt den med en ny. Även
filterinsatsen skall förnyas.
(3) Hur delarna sätts samman
finns beskrivet i 8.2.9 (6)....(8).
