66 AhnLab TrusGuard Installation Guide
• Specify the bridge interface Name (e.g.: br0).
• Select Bridge for Type
• Select more than two Network Interfaces.
• Enter the IPv4 address (if not used, enter 0.0.0.0/0).
• Enter the IPv6 address (if not used, enter ::/0).
• Select the response protocol in Control.
▪ PING: To respond to ICMP ping requests
▪ HTTPS: To allow access to administrative web page
▪ SSH: To allow connection to SSH terminal
▪ ARP: To allow resolution of network layer addresses into link layer addresses
▪ NDP: To allow the operation in the link layer of the Internet model, and address
autoconfiguraiton.
• Select whether to use STP (Spanning Tree Protocol).
▪ Specify the Bridge Priority (0 to 99). The bridge with lower number becomes the root bridge.
3 Click OK.
4 Click Apply.
Note
To use Active-Standby HA bridge, you must specify STP and Bridge Priority.
Note
If you do not allot an IP address of the bridge, uncheck all Control checkboxes.
Interface for Bridge
Bridge can be used in the following interfaces.
Network port using static IP address
Aggregation interface
Convert Connection Using LLCF
You can use the bridge port control commands in a Terminal.
A bridge interface consists of more than 2 network interfaces. When even one of the physical network
port link goes down, Link Loss Carry Forward (LLCF) brings down all the other links in the bridge. Only
when all the ports get linked back, the bridge port will be considered linked. This feature is often used
with routing, and is only available if the network port driver supports LLCF.
list_llcf: Displays LLCF port group list.
