Airzone RADIANT365 - Airzone Lite Setup

40
AIRZONE LITE SETUP
Zone address
Select the zone associated to the thermostat pulling up the microswitch of the corresponding zone.
Associated outputs
If required, select other control outputs associated to the zone. The address zone will be the one with a lower value.
Other settings
Configure other functionalities of the LITE thermostat from the advanced configuration menu of a Blueface thermostat
(see section Advanced Settings, Zone parameters) or Webserver Cloud (see the Installation Manual of the Webserver
Cloud).
