6 Version 1.21
INTRODUCTION
s5000
/
s6000
F1-F16 Function keys down either side of the LCD give direct access to
parameters. Their actual function varies according to the selected
page.
DATA WHEEL This is used to enter data.
CURSOR </> KEYS These are used to move the cursor left or right in parameter fields.
This is particularly useful when editing parameters with long
numeric values such as samples.
These keys are also used in conjunction with the DATA wheel for
naming.
NUMERIC KEYPAD These are used to enter numeric data.
WINDOW This is used to open the ‘window’ function.
UNDO This has no function in Version 1.20 of the operating system.
EXIT This takes you out of the currently selected function and back to
the screen you were in previously.
ENT/PLAY This allows you to audition the currently selected sound.
MARK/JUMP These allow you to mark a page, go to another page and then
jump back and forth between them.
USER KEYS These allow you to assign the pages and functions you use most
often for quick, convenient access. For example, if you find yourself
always going to the FILTER, AMPLITUDE ENVELOPE and
REVERB 1 pages, these may be assigned to each of the USER
KEYS.
DISPLAY CONTRAST This ‘thumbwheel’ control, found on the top/rear of the panel sets
the viewing angle for the LCD.
A screen saver function in UTILITIES allows you to turn the
backlight off at timed intervals to help preserve the LCD.
