● 1 Digit DTMF: set the 1-digt DTMF code within range from ( 0-9 and *,#) if
the DTMF Option is set as “1-digit”.
● 2~4 Digits DTMF: set the DTMF code according to the DMTP Option
setting. For example, you are required to set the 3-digits DTMF code if DTMP
Option is set as 3-digits.
● Relay Status: relay status is low by default which means normally
closed(NC) If the relay status is high, then it is in Normally Open status(NO).
● Relay Name: name the relay switch according to your need. For example,
you can name the relay switch according to where the relay switch is located
for convenience.
13.2.Web Relay Setting
In addition to the relay that is connected to the door phone, you can also control
the door access using the network-based web relay on the device and on the
device web interface.
Web relay needs to be set up on the web Phone > WebRelay interface where
you are required to fill in such information as relay IP address, password, web
relay action, etc before you can achieve the door access via web relay.
Note:
● Only the external devices connected to the relay switch need to be
powered by power adapters as relay switch does not supply power.
●
Note:
● If DTMF mode is set as “1 Digit DTMF”, you cannot edit DTMF
code in “2~4 Digits DTMF” field. And if you set DTMF mode from
2-4 in “2~4 Digits DTMF” field, you can not edit DTMF code in “1
Digit DTMF” field.
