2 Getting Started
Five way navigation key
Left selection key
Speaker
SD card cover panel
RJ12 printer connector
Rubber flap
USB connector
Power supply connector
Reset button
Right selection key
Charging status light
LCD screen
Right select key
Five way navigation key
Left select key
Alere DDS2 Test Cartridge slot
Power button
2.1 Alere DDS2 Mobile Analyser at a glance
