ALLEN & HEATH SQ-5 User Manual

 109
Reference Guide V1.5.0
FX Send
or
L
PFL
PFL
FADER
L
From:
Ret to AUX/FX
FX SEND
R
FX RETURN x8
AFL
AFL
Send > Return FX
R
Strip METER
RackFX x8
Any MIX
Ret to MAIN
LEV
Post
FADER
in-place
Inserted FX
DCA
Input DIR OUT
Pre
Ret to GRP
PEQ
MUTE
MUTE
ASSIGN+PAN
METER
Pink Noise
OUTPUT SOCKET
MUTE
Bandpass Noise (Sweep)
Assign to: INPUT CH, GRP, AUX, MAIN, MTX
White Noise
Assign to: GRP, AUX, MAIN, MTX,
LEV
Sine (Sweep 20-20kHz)
HPF
TALKBACK
Press to TALK
SIG GEN
PAFL Meter
PFL/AFL MONITOR
DELAY
Listen L/R/M
+
PAFL L/R
POL
Linked
(AFL not affected)
PFL TRIM
0
TRIM
DELAY
+
-24dB
EXT IN
Meters RTA
Listen Level
0dB

ALLEN & HEATH SQ-5 Specifications

General

Mixing Channels	48
Local Mic/Line Inputs	16
USB Interface	Yes
Type	Digital Mixer
Inputs - Mic Preamps	16
Inputs - Line	16
Talkback	Yes
EQ Bands	4-band Parametric
I/O Expansion Slots	1
Effects Processors	8
Power Supply	Internal
Local Line Outputs	8
Touchscreen	7-inch Capacitive Touchscreen
Dante Option	Yes (with optional card)
Weight	10.5 kg
Effects	8 Stereo FX Engines
Data I/O	Ethernet
Computer Connectivity	USB, Ethernet
Faders	16
A/D Resolution	96kHz / 48kHz
Processing	96kHz
Connectivity	USB, Ethernet
USB Audio	32 x 32
Expansion	Optional Dante, Waves, SLink cards
Display	7-inch Capacitive Touchscreen
