63
Reference Guide V1.5.0
11.3 Safes
‘Safes’ block any changes to a channel when recalling a scene.
Touch ‘Input’, ‘FX’ or ‘Mixtabs to view all channel safes.
Touch a ‘Safebutton to safe the channel (the button will turn white).
11.4 Libraries
Factory Libraries and User Libraries are available for many features and processing in
SQ and can be accessed by using the dedicated Library key when in certain screens.
Throughout this document, where a library is available for use, it is noted
with an image of the library key next to the screen image.
safe disabled
safe enabled
options/folders
rename
Factory/User libraries
library items
storage/recall
