64
Reference Guide V1.5.0
Factory libraries provide presets and are also used to recall different FX units or DEEP
plug-ins. They are fixed in firmware and cannot be edited or overwritten.
To recall from the library:
Go to the screen you wish to recall parameters for.
Press the ‘Library’ key.
Select the Factory or User library item you wish to recall.
Touch the ’Recall button.
To store or overwrite a library item:
Go to the screen you wish to store parameters for with the settings you wish to
store visible.
Press the ‘Library’ key.
Select the User library in the top right of the screen.
Touch the ’Store New button to store a new library item.
OR
Select a library item and touch the ‘Overwrite’ button.
To delete a library item:
Select the User library in the top right of the screen.
Select the library item you wish to delete.
Touch the ’Delete button then confirm to delete the item.
Libraries are available in the following screens.
SQ Libraries
Library
Screen
Includes
Input Channel
Processing overview
(input selected)
All input channel processing - Options for Preamp, Name and
Colour recall
Mix Channel
Processing overview
(mix selected)
All mix channel processing - Options for Ext In Preamp, Name
and Colour recall
Preamp Model
Processing > Preamp
(input selected)
DEEP preamp model and parameters
Gate
Processing > Gate
Gate parameters
GEQ
Processing > GEQ
DEEP GEQ models and parameters
PEQ
Processing > PEQ
PEQ parameters - Option for HPF
Compressor
Processing > Compressor
DEEP compressor models and parameters
FX
FX (rack selected)
FX units and parameters, including Wet/Dry mix
User
Permissions
Setup > Users
(User 1- 10 selected)
User permission settings
Input Channel
Patch
I/O > Inputs
All patching for Input Channel and Mix Ext In
