ALLEN & HEATH SQ-5 User Manual

 110
Reference Guide V1.5.0
19. Specifications
Mic/Line Inputs
Balanced XLR, fully recallable
Input Sensitivity
-60 to +0dBu
Switchable Pad
-20dB
Analogue Gain
0dB to +60dB, 1dB steps
Maximum Input Level
+30dBu
Input Impedance
>5kΩ
THD+N, Unity gain 0dB
0.002% -92dBu (20Hz-20kHz, AES Direct Out, @0dBu
1kHz)
THD+N, Mid gain +30dB
0.003% -91dBu (20Hz-20kHz, AES Direct Out, @-30dBu
INPUT 1kHz)
Phantom Power
+48V (+3V / -2V)
Stereo Line Inputs
ST1, ST2 connectors
Balanced, 1/4" TRS jack
ST3 connector
Unbalanced, stereo 3.5mm Mini Jack
Input Sensitivity (ST1, ST2 / ST3)
Nominal +4dBu ST1, ST2 / 0dBu ST3
Trim
+/-24dB
Maximum Input Level (ST1, ST2 / ST3)
+22dBu / +18dBu
Input Impedance
>7kΩ
Outputs 1-12 (SQ-5) and 1-14 (SQ-6)
Balanced, XLR
Outputs A and B
Balanced 1/4" TRS Jack
Source
Patchable
Output Impedance
<75Ω
Nominal Output
+4dBu = 0dB meter reading
Maximum Output Level
+22dBu
Residual Output Noise
-90dBu (muted, 20Hz-20kHz)
AES Digital Output
Balanced XLR 2 channel,
96kHz sampling rate (Default with SRC Bypassed)
Switchable output sample rates,44.1kHz/ 48kHz/ 88.2kHz/
(96kHz)
2.5Vpp balanced terminated 110Ω

ALLEN & HEATH SQ-5 Specifications

General

Mixing Channels	48
Local Mic/Line Inputs	16
USB Interface	Yes
Type	Digital Mixer
Inputs - Mic Preamps	16
Inputs - Line	16
Talkback	Yes
EQ Bands	4-band Parametric
I/O Expansion Slots	1
Effects Processors	8
Power Supply	Internal
Local Line Outputs	8
Touchscreen	7-inch Capacitive Touchscreen
Dante Option	Yes (with optional card)
Weight	10.5 kg
Effects	8 Stereo FX Engines
Data I/O	Ethernet
Computer Connectivity	USB, Ethernet
Faders	16
A/D Resolution	96kHz / 48kHz
Processing	96kHz
Connectivity	USB, Ethernet
USB Audio	32 x 32
Expansion	Optional Dante, Waves, SLink cards
Display	7-inch Capacitive Touchscreen
