ALLEN & HEATH SQ-5 User Manual

 111
Reference Guide V1.5.0
SLink Connection
Neutrik etherCON (RJ45)
dSnake mode (48kHz devices)
40 input 20+40(ME) output channels
dx mode (96kHz devices)
32 input 32 output channels
gigaACE/GX mode (96kHz devices)
128 input 128 output channels
Inputs
Fully Patchable
Outputs
Fully Patchable
Sync/SRC
Assignable as master audio sync for all modes, SRC 64
channel
I/O Port
Multi-channel IO option module
Inputs
Fully Patchable
Outputs
Fully Patchable
Sync/SRC
Assignable as master audio sync
System
Measured balanced XLR in to XLR out, 0dB gain,
0dBu input
Dynamic Range
112 dB
Frequency Response
+0/-0.5dB 20Hz to 20kHz
Headroom
+18dB
Internal operating Level
0dBu
THD+N, Mic/Line routed to Main L/R Out
Unity gain faders@0dB, 0.006%, -84dBu (20 - 20kHz)
dBFS Alignment
+18dBu = 0dBFS (+22dBu at XLR output)
Meter Calibration
0dB meter = -18dBFS (+4dBu at XLR out)
Main Meter Type
2 x 12 segment, fast (peak) response
Channel Meter Type
Chromatic Channel Metering, fully programmable
colour/brightness
Peak Indication
-3dBFS (+19dBu at XLR out), multi-point sensing
Sampling Rate
96kHz
Bit Depth
Uses XCVI core custom bit widths in algorithms, up to
96bits
Latency
<0.7mS, Local Mic Input to Main L/R
Operating Temperature Range
0 deg C to 40 deg C (32 deg F to 104 deg F)
Mains Power
100-240V AC, 50/60Hz
Max Power Consumption SQ-5/SQ-6/SQ-7
75W / 90W / 110W

ALLEN & HEATH SQ-5 Specifications

General

Mixing Channels	48
Local Mic/Line Inputs	16
USB Interface	Yes
Type	Digital Mixer
Inputs - Mic Preamps	16
Inputs - Line	16
Talkback	Yes
EQ Bands	4-band Parametric
I/O Expansion Slots	1
Effects Processors	8
Power Supply	Internal
Local Line Outputs	8
Touchscreen	7-inch Capacitive Touchscreen
Dante Option	Yes (with optional card)
Weight	10.5 kg
Effects	8 Stereo FX Engines
Data I/O	Ethernet
Computer Connectivity	USB, Ethernet
Faders	16
A/D Resolution	96kHz / 48kHz
Processing	96kHz
Connectivity	USB, Ethernet
USB Audio	32 x 32
Expansion	Optional Dante, Waves, SLink cards
Display	7-inch Capacitive Touchscreen
