ALLEN & HEATH SQ-5 User Manual

 114
Reference Guide V1.5.0
USB Audio
SQ-Drive
USB A
Stereo Record
2 channel, 48/96kHz, 24-bit, fully patchable
Stereo Playback
1/2 channel, 44.1/48/96kHz 16/24-bit, fully patchable
Multitrack Record
1-16 channel 96kHz, 1-32 channel 48kHz, 24-bit, WAV,
fully patchable
Multitrack Playback
1-16 channel 96kHz, 1-32 channel 48kHz, 24-bit, WAV,
fully patchable
USB Audio Streaming
USB-B, Core Audio compliant, ASIO/WDM for Windows
Send (upstream)
32 channel, 48/96kHz, 24-bit
Return (downstream)
32 channel, 48/96kHz, 24-bit
Size and Weight
SQ-5
Width x Depth x Height
Desk mounted
440 x 514.9 x 198 mm (17.3" x 20.3" x 7.8")
Packed in shipping box
610 x 680 x 360 mm (24" x 26.8" x 14.2")
Unpacked weight
10.5 kg (23.1 lbs)
Packed weight
14 kg (30.9 lbs)
SQ-6
Width x Depth x Height
Desk mounted
638 x 514.9 x 198 mm (25.1" x 20.3" x 7.8")
Packed in shipping box
820 x 680 x 360 mm (32.3" x 26.8" x 14.2")
Unpacked weight
14.5 kg (32 lbs)
Packed weight
17.3 kg (38.1 lbs)
SQ-7
Width x Depth x Height
Desk mounted
804 x 514.9 x 198 mm (31.7" x 20.3" x 7.8")
Packed in shipping box
960 x 685 x 360 mm (37.8" x 27" x 14.2")
Unpacked weight
17.8 kg (39.3 lbs)
Packed weight
21.9 kg (48.3 lbs)

ALLEN & HEATH SQ-5 Specifications

General

Mixing Channels	48
Local Mic/Line Inputs	16
USB Interface	Yes
Type	Digital Mixer
Inputs - Mic Preamps	16
Inputs - Line	16
Talkback	Yes
EQ Bands	4-band Parametric
I/O Expansion Slots	1
Effects Processors	8
Power Supply	Internal
Local Line Outputs	8
Touchscreen	7-inch Capacitive Touchscreen
Dante Option	Yes (with optional card)
Weight	10.5 kg
Effects	8 Stereo FX Engines
Data I/O	Ethernet
Computer Connectivity	USB, Ethernet
Faders	16
A/D Resolution	96kHz / 48kHz
Processing	96kHz
Connectivity	USB, Ethernet
USB Audio	32 x 32
Expansion	Optional Dante, Waves, SLink cards
Display	7-inch Capacitive Touchscreen
