ALLEN & HEATH SQ-5 User Manual

 15
Reference Guide V1.5.0
Utility
General
Diagnostics
Calibration
MIDI
Add-ons
Data
Shows
Scenes
Libraries
Sync
USB Utility
Status/Format
Firmware Update
SQ-Drive
Stereo
Multitrack
Auto Mic Mixer
Overview
Input Assign
Setup
I/O
Inputs/Input channel
Input sources
Inputs/Mix Ext In
Outputs/IP Direct Out
Output destinations
Outputs/Mix Out
Outputs/Rack FX
Outputs/Monitor Out
Tie Lines/All Input Sources
All Output Destinations

ALLEN & HEATH SQ-5 Specifications

General

Mixing Channels	48
Local Mic/Line Inputs	16
USB Interface	Yes
Type	Digital Mixer
Inputs - Mic Preamps	16
Inputs - Line	16
Talkback	Yes
EQ Bands	4-band Parametric
I/O Expansion Slots	1
Effects Processors	8
Power Supply	Internal
Local Line Outputs	8
Touchscreen	7-inch Capacitive Touchscreen
Dante Option	Yes (with optional card)
Weight	10.5 kg
Effects	8 Stereo FX Engines
Data I/O	Ethernet
Computer Connectivity	USB, Ethernet
Faders	16
A/D Resolution	96kHz / 48kHz
Processing	96kHz
Connectivity	USB, Ethernet
USB Audio	32 x 32
Expansion	Optional Dante, Waves, SLink cards
Display	7-inch Capacitive Touchscreen
