ALLEN & HEATH SQ-5 User Manual

 30
Reference Guide V1.5.0
• Adjust parameters by touching to select and then using the touchscreen rotary.
Gate threshold also has a dedicated rotary.
Attack = 50µs to 300ms
Hold = 10ms to 5secs
Release= 10ms to 1sec
Threshold = -72dB to +18dB
Depth = 0dB to 60dB
Histogram –
The histogram shows the previous 12 seconds of gate activity, moving from right to
left. As with the reduction meter, when the gate is in, the level reduction (depth) is
shown in red, and when out is shown in white/grey.

ALLEN & HEATH SQ-5 Specifications

General

Mixing Channels	48
Local Mic/Line Inputs	16
USB Interface	Yes
Type	Digital Mixer
Inputs - Mic Preamps	16
Inputs - Line	16
Talkback	Yes
EQ Bands	4-band Parametric
I/O Expansion Slots	1
Effects Processors	8
Power Supply	Internal
Local Line Outputs	8
Touchscreen	7-inch Capacitive Touchscreen
Dante Option	Yes (with optional card)
Weight	10.5 kg
Effects	8 Stereo FX Engines
Data I/O	Ethernet
Computer Connectivity	USB, Ethernet
Faders	16
A/D Resolution	96kHz / 48kHz
Processing	96kHz
Connectivity	USB, Ethernet
USB Audio	32 x 32
Expansion	Optional Dante, Waves, SLink cards
Display	7-inch Capacitive Touchscreen
