ALLEN & HEATH SQ-5 User Manual

 61
Reference Guide V1.5.0
Mix Filters –
Group
Filter
Includes
Patch
Mix Ext In source plus output patching of Group channels
Ext In Preamp
Preamp settings of Group Mix Ext In
Processing
All Group channel processing
Name/Colour
All Group channel names and colours
Fader
Master fader positions and output balance of Group channels
Pan/Balance
Master pan and balance positions for all Group channels
Mute
Master mute for all Group channels
Assigns to Group
All channel assignments to all groups
Aux
Filter
Includes
Patch
Mix Ext In source plus output patching of Aux channels
Ext In Preamp
Preamp settings of Aux Mix Ext In
Processing
All Aux channel processing
Name/Colour
All Aux channel names and colours
Fader
Master fader positions and output balance of Aux channels
Mute
Master mute for all Aux channels
Sends to Aux
All send levels to Aux channels
Main
Filter
Includes
Patch
Mix Ext In source plus output patching of the Main LR channel
Ext In Preamp
Preamp settings of Main LR Mix Ext In
Processing
Main LR channel processing
Name/Colour
Main LR channel name and colour
Fader
Master fader positions and output balance of the Main LR channel
Mute
Master mute for all Main LR channel
Matrix
Filter
Includes
Patch
Mix Ext In source plus output patching of Matrix channels
Ext In Preamp
Preamp settings of Matrix Mix Ext In
Processing
All Matrix channel processing
Name/Colour
All Matrix channel names and colours
Fader
Master fader positions and output balance of Matrix channels
Mute
Master mute for all Matrix channels
Sends to Matrix
All send levels to Matrix channels

ALLEN & HEATH SQ-5 Specifications

General

Mixing Channels	48
Local Mic/Line Inputs	16
USB Interface	Yes
Type	Digital Mixer
Inputs - Mic Preamps	16
Inputs - Line	16
Talkback	Yes
EQ Bands	4-band Parametric
I/O Expansion Slots	1
Effects Processors	8
Power Supply	Internal
Local Line Outputs	8
Touchscreen	7-inch Capacitive Touchscreen
Dante Option	Yes (with optional card)
Weight	10.5 kg
Effects	8 Stereo FX Engines
Data I/O	Ethernet
Computer Connectivity	USB, Ethernet
Faders	16
A/D Resolution	96kHz / 48kHz
Processing	96kHz
Connectivity	USB, Ethernet
USB Audio	32 x 32
Expansion	Optional Dante, Waves, SLink cards
Display	7-inch Capacitive Touchscreen
