ALLEN & HEATH SQ-5 User Manual

 68
Reference Guide V1.5.0
Sync –
To push or pull data using the SQ-MixPad app, the SQ console must be in sync mode.
This avoids accidental overwriting of data on both the SQ console and SQ-MixPad.
To enter sync mode, go to the ‘Utility’ screen, then touch ‘Data’ followed by ‘Sync’.
Touch the ‘Sync Mode’ button then confirm you understand the implications of sync
mode in the pop-up to proceed.
Once in sync mode, pushing and pulling of data is controlled by SQ-MixPad.
 User permissions for the current user of both the console and SQ-MixPad must allow
‘Sync Push’ and/or ‘Sync Pull’ to transfer a show.
 Refer to SQ-MixPad help for more information on data transfer to and from MixPad.
 Starting sync mode will disconnect all devices aside from the one being connected to as
all network bandwidth is required without interruption.
sync mode

ALLEN & HEATH SQ-5 Specifications

General

Mixing Channels	48
Local Mic/Line Inputs	16
USB Interface	Yes
Type	Digital Mixer
Inputs - Mic Preamps	16
Inputs - Line	16
Talkback	Yes
EQ Bands	4-band Parametric
I/O Expansion Slots	1
Effects Processors	8
Power Supply	Internal
Local Line Outputs	8
Touchscreen	7-inch Capacitive Touchscreen
Dante Option	Yes (with optional card)
Weight	10.5 kg
Effects	8 Stereo FX Engines
Data I/O	Ethernet
Computer Connectivity	USB, Ethernet
Faders	16
A/D Resolution	96kHz / 48kHz
Processing	96kHz
Connectivity	USB, Ethernet
USB Audio	32 x 32
Expansion	Optional Dante, Waves, SLink cards
Display	7-inch Capacitive Touchscreen
