ALLEN & HEATH SQ-5 User Manual

 73
Reference Guide V1.5.0
Possible SoftKey assignments
Control Type
Control Option 1
Control Option 2
Colour
Unassigned
N/A
N/A
N/A
AMM Channel On/Off
N/A
All input channels
Green
AMM In/Out
N/A
AMM 1, AMM 2
Green
Channel Mute
N/A
All audio channels
Red
Channel PAFL
N/A
All audio channels
Yellow
DAW Control
N/A
Bank Up, Bank Down
N/A
DCA Mute
N/A
DCA’s 1 to 8
Red
DCA PAFL
N/A
DCA’s 1 to 8
Yellow
DCA Spill
N/A
Spill On Sel, DCA's 1 to 8
Magenta/
Green
MIDI note On/Off
MIDI Channel
Note
Red
MIDI Program change
MIDI Channel
Program 0 - 127
Red
Mix Select
N/A
All mixes
Blue/Magenta
MMC
N/A
Rewind, Play, Pause, Stop,
FFwd, Record
Red
Mute Group
N/A
Mute Groups 1 to 8
Red
PAFL Clear
N/A
N/A
Red
Recall Scene
N/A
All saved scenes
Red
Scene Next
N/A
N/A
Red
Scene Previous
N/A
N/A
Red
Scene Recall Go
None, Auto Increment
N/A
Red
Scene Store Current
N/A
N/A
Red
SQ Drive Multitrack
N/A
Previous, Stop,
Start/Pause, Arm recording,
Next, Arm/Rec/Stop
Blue/Red/
Green
SQ Drive Stereo Play
N/A
Previous, Stop,
Start/Pause, Next
Blue/Red/
Green
SQ Drive Stereo Record
N/A
Stop, Start/Pause, Arm
recording, Arm/Rec/Stop
Blue/Red/
Green
Talk
N/A
N/A
Green
Tap Tempo
Left, Right, Left & Right
FX engines 1 to 8
Yellow
Global Tap Tempo
N/A
N/A
Yellow

ALLEN & HEATH SQ-5 Specifications

General

Mixing Channels	48
Local Mic/Line Inputs	16
USB Interface	Yes
Type	Digital Mixer
Inputs - Mic Preamps	16
Inputs - Line	16
Talkback	Yes
EQ Bands	4-band Parametric
I/O Expansion Slots	1
Effects Processors	8
Power Supply	Internal
Local Line Outputs	8
Touchscreen	7-inch Capacitive Touchscreen
Dante Option	Yes (with optional card)
Weight	10.5 kg
Effects	8 Stereo FX Engines
Data I/O	Ethernet
Computer Connectivity	USB, Ethernet
Faders	16
A/D Resolution	96kHz / 48kHz
Processing	96kHz
Connectivity	USB, Ethernet
USB Audio	32 x 32
Expansion	Optional Dante, Waves, SLink cards
Display	7-inch Capacitive Touchscreen
