ALLEN & HEATH SQ-5 User Manual

 77
Reference Guide V1.5.0
Channel Delay Controls –
‘Delay Units’ changes the units displayed on all input and mix processing channel
delays.
Delay Units = Millisecond (ms)
Meters (m)
Feet (ft)
Samples (S)
As the speed of sound through air depends on the temperature of the air, selecting a
measure of distance will allow the ‘Temperature’ value to be changed. This should be
set to match the ambient temperature of the air.
Temperature = -20°C to +40°C
-4°F to +104°F
 If Meters is selected, temperature is shown in Celsius. If Feet is selected, temperature is
shown in Fahrenheit.
 Note that these values extend outside the operating temperature range of the SQ.
Brightness –
These settings individually control the brightness of illumination across the SQ.
• Touch a parameter dial and adjust using the touchscreen rotary.
Touchscreen = The touchscreen backlight
LED’s = All surface LED’s including keys, channel and PAFL metering
Channel Strip LCDs = Channel naming strip LCD backlights
Light Bar Brightness = Brightness of the integrated illumination
Light Bar Balance = Colour of the integrated illumination

ALLEN & HEATH SQ-5 Specifications

General

Mixing Channels	48
Local Mic/Line Inputs	16
USB Interface	Yes
Type	Digital Mixer
Inputs - Mic Preamps	16
Inputs - Line	16
Talkback	Yes
EQ Bands	4-band Parametric
I/O Expansion Slots	1
Effects Processors	8
Power Supply	Internal
Local Line Outputs	8
Touchscreen	7-inch Capacitive Touchscreen
Dante Option	Yes (with optional card)
Weight	10.5 kg
Effects	8 Stereo FX Engines
Data I/O	Ethernet
Computer Connectivity	USB, Ethernet
Faders	16
A/D Resolution	96kHz / 48kHz
Processing	96kHz
Connectivity	USB, Ethernet
USB Audio	32 x 32
Expansion	Optional Dante, Waves, SLink cards
Display	7-inch Capacitive Touchscreen
