ALLEN & HEATH SQ-5 User Manual

 79
Reference Guide V1.5.0
Ext in Source Select and Ext in Preamp/Trim –
Use these settings to select an external in socket to feed directly to the PAFL bus.
Preamp control will become available when a local or remote preamp has been
assigned.
Use the ‘Ext in to PAFL’ button to switch the external in signal on or off.
 This feature is intended for communication between two systems, so it is active
even when the PAFL bus is being used to monitor channels.
Input to PAFL Source Point –
Select where in the channel the PAFL signal is sourced from.
Post Preamp = Signal is affected by preamp only
Post Insert Return = Also includes DEEP Preamp, HPF, Gate and Insert
Post PEQ = Also includes PEQ
Post Delay = Also includes Compressor and Channel Delay
 Note that ‘Post Preamp’ setting does not include DEEP Preamp processing.
PFL Trim –
The PFL trim attenuates the level of PFL signal routed to the PAFL bus. It does not
affect AFL.
PFL Trim = -24dB to 0dB
Delay –
The PAFL delay can be used to align the PAFL bus when, in a live sound
environment, the naturally delayed sound from a sound system can be heard at the
same time as the otherwise instant signal fed to headphones or monitors, causing
phase issues or an audible delay.
PAFL bus delay = 0ms to 682.6ms
Listen Level –
The Listen bus is fed by the PAFL signal and can be patched to an output socket. The
Listen Level affects the output level of this bus.
Listen Level = -Inf to +10dB
 The Listen Level can also be controlled by the master fader. See the Mixer Role section
of this guide for more information.

ALLEN & HEATH SQ-5 Specifications

General

Mixing Channels	48
Local Mic/Line Inputs	16
USB Interface	Yes
Type	Digital Mixer
Inputs - Mic Preamps	16
Inputs - Line	16
Talkback	Yes
EQ Bands	4-band Parametric
I/O Expansion Slots	1
Effects Processors	8
Power Supply	Internal
Local Line Outputs	8
Touchscreen	7-inch Capacitive Touchscreen
Dante Option	Yes (with optional card)
Weight	10.5 kg
Effects	8 Stereo FX Engines
Data I/O	Ethernet
Computer Connectivity	USB, Ethernet
Faders	16
A/D Resolution	96kHz / 48kHz
Processing	96kHz
Connectivity	USB, Ethernet
USB Audio	32 x 32
Expansion	Optional Dante, Waves, SLink cards
Display	7-inch Capacitive Touchscreen
