ALLEN & HEATH SQ-5 User Manual

 94
Reference Guide V1.5.0
Playback –
• Touch the ‘Stereo Playback’ file name value. Then touch the ‘Playback’ or
‘Recording’ button to view files in each folder (recordings you have made with
the SQ are displayed in the ‘Recordings’ folder).
• Touch a track to highlight it.
• Touch the ‘Select’ button to load the highlighted track.
• Touch the ‘Playback Mode’ value to select a mode.
Play All = Play all tracks in the folder consecutively.
Play Single = Play the selected track then stop.
Repeat All = Repeatedly play all tracks in the folder consecutively.
Repeat Single = Repeatedly play the selected track.
• Touch the transport buttons to go to the previous or next track, or to stop or
play/pause.
• Touch and drag the circular playback position marker to jump to a different point
in the track.
Formats and Folders –
SQ-Drive stores stereo recordings to ‘<SQ-DRIVE>:\AHSQ\USBREC’.
These are 96kHz or 48kHz 24bit stereo *.wav files, named sequentially in the order
recorded i.e. SQ-ST001.WAV, SQ-ST002.WAV…
Files for stereo playback copied from a computer should be placed in
‘<SQ-DRIVE>:\AHSQ\USBPLAY’.
These can be mono or stereo, uncompressed PCM *.wav files, 44.1, 48 or 96kHz and
16 or 24-bit.
They must not contain any headers (such as BWF) or data (such as markers).
Length of Recording –
The maximum length of a stereo recording is approximately 2 hrs and will use around
4GB of storage.

ALLEN & HEATH SQ-5 Specifications

General

Mixing Channels	48
Local Mic/Line Inputs	16
USB Interface	Yes
Type	Digital Mixer
Inputs - Mic Preamps	16
Inputs - Line	16
Talkback	Yes
EQ Bands	4-band Parametric
I/O Expansion Slots	1
Effects Processors	8
Power Supply	Internal
Local Line Outputs	8
Touchscreen	7-inch Capacitive Touchscreen
Dante Option	Yes (with optional card)
Weight	10.5 kg
Effects	8 Stereo FX Engines
Data I/O	Ethernet
Computer Connectivity	USB, Ethernet
Faders	16
A/D Resolution	96kHz / 48kHz
Processing	96kHz
Connectivity	USB, Ethernet
USB Audio	32 x 32
Expansion	Optional Dante, Waves, SLink cards
Display	7-inch Capacitive Touchscreen
