Rockwell Automation Publication 193-UM014C-EN-P - August 2016 63
Automation Controller Communication Chapter 7
ControlLogix Generic Configuration
An existing project can be used or a new project can be created to configure
EtherNet/IP I/O Messaging. To create a new project, perform the following
steps.
1. Select File>New from the RSLogix 5000.
2. Select the controller type, chassis type, slot number, and project path.
Then, enter a name for the controller and click OK.
3. Right-click the I/O Configuration folder, then select New Module. The
Select Module Type window appears.
