162 Rockwell Automation Publication 5069-UM004A-EN-P - April 2019
Chapter 6 Configure a Standard Module
Edit the Module
Configuration Common
Categories
You click the category names in the New Module dialog box to view and
change the configuration parameters. Before you edit the module
configuration, consider the following:
• This chapter shows how to edit configuration when you add the module
to the Logix Designer application project.
If you access the module configuration after it is added to the project,
the dialog box is named Module Properties. The same categories are
displayed as the categories displayed on the New Module dialog box.
• Some new module configuration categories apply to all Compact 5000
I/O digital modules. Some categories are specific to the module type.
For example purposes, the figures in this section are from a 5069-IB16
module.
The following categories apply to all Compact 5000 I/O standard modules and
are described in this section.
•
General Category
•
Connection Category
•
Module Info Category
General Category
The General category appears first when you create a module. The parameters
in this category are the same for all Compact 5000 I/O digital modules.
You use this category to complete the following optional tasks:
• Name the module.
• Assign a slot number. (required)
• Describe the module.
• Access the Module Definition.
