240 Rockwell Automation Publication 5069-UM004A-EN-P - April 2019
Appendix B Module Tag Definitions
Event Input Tags
Table 65 describes the 5069-IB16F module event input tags. The event input
tags are displayed only if Data with Events is selected in the Module Definition
window.
Ptxx.TimestampLatchEn BOOL When this bit is set, timestamps are latched; this means
that a Timestamp is not overwritten until acknowledged.
All subsequent transitions on that point are ignored until
acknowledged/reset.
If the bit is not set, the new LO Timestamp overwrites the
first LO Timestamp immediately, even if the controller has
yet to extract that data.
You can acknowledge the timestamp in the
following ways:
• Off to On transition timestamp:
The Ptxx.TimestampOffOnNumber.x input tag value is
written to the Ptxx.TimestampxxxxxNumberAck
output tag value.
If Timestamp Latching is enabled, the
Ptxx.Timestampxxxx input tag remains the same until
the next input Off to On transition occurs. Otherwise,
the input tag value is cleared.
• On to Off transition timestamp:
The Ptxx.TimestampOnOffNumber.x input tag value is
written to the Ptxx.TimestampxxxxxNumberAck
output tag value.
If Timestamp Latching is enabled, the
Ptxx.Timestampxxxx input tag remains the same until
the next input On to Off transition. Otherwise, the
input tag value is cleared.
• 0 = Timestamps are overwritten with each
successive COS transition.
• 1 = Timestamps are latched until
acknowledged.
Table 64 - 5069-IB16F Module Configuration Tags
Name Size Definition Valid Values
Table 65 - 5069-IB16F Module Event Input Tags
Name Size Definition Valid Values
RunMode BOOL Channel’s operating state • 0 = Idle
• 1 = Run Mode
ConnectionFaulted BOOL Indicates if a connection is running.
The module sets this tag to 0 when connected. If the
module is not connected, it changes the tag to 1.
• 0 = Connection running
• 1 = Connection not running
Diagnostic Active BOOL Indicates if any diagnostics are active or if the prognostics
threshold is reached.
• 0 = No diagnostics active
• 1 = One or more diagnostics are active or the
prognostics threshold is reached
DiagnosticSequence Count SINT Increments for each time a distinct diagnostic condition is
detected, and when a distinct diagnostic condition
transitions from detected to not detected.
Set to zero by product reset or power cycle. Wraps from
255 (-1) to 1 skipping zero.
-128…+127
The value of 0 is skipped except during module
power-up.
Eventx BOOL Indicates the number of the event. 0…3
