Rockwell Automation Publication 5069-UM004A-EN-P - April 2019 269
Module Tag Definitions Appendix B
Output Tags
Table 90 describes the 5069-IB8S or 5069-IB8SK module output tags.
Testxx.Fault BOOL Indicates one of the following:
• The channel data is inaccurate and cannot be trusted
for use in the application.
For more information, see
Module Data
Quality Reporting on page 71.
• The channel is set to Not Used.
• 0 = Good data
• 1 = Bad data (faulted) or set to Not Used
If the tag is set to 1, you must troubleshoot the
module to correct the cause of the inaccuracy.
IMPORTANT: Once the condition that causes
the tag to change to 1 is removed, you must
complete the steps described in
Safety Input
Fault Recovery on page 138 to reset this tag
to 0.
(1)
If the tag is 1 because the channel is set to Not
Used, no action is required.
Testxx.Uncertain BOOL Indicates that the channel data can be inaccurate but the
degree of inaccuracy is not known.
For more information, see Module Data Quality Reporting
on page 71.
• 0 = Good data
• 1 = Uncertain data
This tag is set to 1 when the module has
reached a critical operating temperature or is
higher the acceptable operating temperature.
IMPORTANT: Once the condition that causes
the tag to change to 1 is removed, the tag
automatically resets to 0.
Testxx.ShortCircuit BOOL Indicates an output short circuit • 0 = No short circuit
• 1 = Short circuit
Testxx.FieldPowerOff BOOL Indicates that a field power loss condition exists on the
channel.
• 0 = No field power off condition
• 1 = Field power off condition
Testxx.Status BOOL Indicates the channel status. • 0 = Fault
• 1 = Good
(1) If the Point Mode for the test output is Pulse Test or Power Supply when the Short Circuit condition is detected, the condition can be corrected but you cannot set the test output to a safety state.
Table 89 - 5069-IB8S or 5069-IB8SK Module Input Tags
Name Data Type Definition Valid Values
Table 90 - 5069-IB8S or 5069-IB8SK Module Output Tags
Name Size Definition Valid Values
Mutingxx.Data BOOL Indicates the current muting value • 0 = Off
• 1 = On
