Module Tag Definitions Appendix B
5069-IA16 Module Tags
This section describes the tags that are associated with the 5069-IA16 module.
Configuration Tags
Table 59 describes the 5069-IA16 module configuration tags.
DC INPUT
5069-IB16
DC OUTPUT
5069-OB16
ANALOG INPUT
5069-IY4
SA Power MOD Power
ANALOG OUTPUT
5069-OF8
DC INPUT
5069-IB16
Standard Modules
Table 59 - 5069-IA16 Module Configuration Tags
Name Data Type Definition Valid Values
Ptxx.InputOffOnFilter SINT The amount of time that a signal must be in the on state
before the input data indicates the on state.
The amount of time is indicated using an enumeration.
Not all products support all enumeration values.
The valid values are determined by the input
signal.
Input signal is 120V AC.
• 13 = 1 ms
Input signal is 240V AC.
• 13 = 1 ms
• 14 = 2 ms
• 15 = 5 ms
IMPORTANT: Logix Designer application lets you
enter tag values for filter values that are invalid
for some input signals.
Make sure that you select a valid input filter value.
If you select an invalid input filter value, the
module can read signal levels incorrectly.
Ptxx.InputOnOffFilter SINT The amount of time that a signal must be in the off state
before the input data indicates the off state.
The amount of time is indicated using an enumeration.
Not all products support all enumeration values.
Input signal is 120V AC:
• 16 = 10 ms
• 17 = 20 ms
Input signal is 240V AC:
• 15 = 5 ms
• 16 = 10 ms
• 17 = 20 ms
