Rockwell Automation Publication 5069-UM004A-EN-P - April 2019 249
Module Tag Definitions Appendix B
Event Input Tags
Table 70 describes the 5069-IB6F-3W module event input tags. The event
input tags are displayed only if you select Data with Events in the Module
Definition window.
Table 70 - 5069-IB6F-3W Module Event Input Tags
Name Size Definition Valid Values
ConnectionFaulted BOOL Indicates if a connection is running.
The module sets this tag to 0 when connected. If the
module is not connected, it changes the tag to 1.
• 0 = Connection running
• 1 = Connection not running
DiagnosticActive BOOL Indicates if any diagnostics are active or if the prognostics
threshold is reached.
• 0 = No diagnostics active
• 1 = One or more diagnostics are active or the
prognostics threshold is reached
DiagnosticSequenceCount SINT Increments for each time a distinct diagnostic condition is
detected, and when a distinct diagnostic condition
transitions from detected to not detected.
Set to zero by product reset or power cycle. Wraps from
255 (-1) to 1 skipping zero.
-128…+127
The value of 0 is skipped except during module
power-up.
RunMode BOOL Channel’s operating state • 0 = Idle
• 1 = Run Mode
Eventx BOOL Indicates the number of the event. 0…3
Eventx.Fault BOOL Detects whether the signal is good data. The fault is set to
1 by the originator when the connection is lost.
• 0 = Good data
• 1 = Bad data (Faulted)
Eventx.Uncertain BOOL Indicates that the channel data can be inaccurate but the
degree of inaccuracy is not known.
For more information, see
Module Data Quality Reporting
on page 71.
• 0 = Good data
• 1 = Uncertain data
If the tag is set to 1, you must troubleshoot the
module to correct the cause of the inaccuracy.
IMPORTANT: Once the condition that causes
the tag to change to 1 is removed, the tag
automatically resets to 0.
Eventx.EventDropped BOOL Indicates when an event has been discarded because
events are occurring faster than they are being
acknowledged.
• 0 = An event status has not been dropped.
• 1 = An event status has been dropped.
Eventx.EventRising BOOL Indicates whether an event triggered when an input
transition results in an event pattern being matched.
0 or 1
Eventx.EventFalling BOOL Indicates whether an event triggered when an input
transition resulted in an event pattern no longer being
matched.
0 or 1
Eventx.CIPSyncValid BOOL Indicates whether the module is synced with a 1588
master.
• 0 = CIP Sync is not available
• 1 = CIP Sync is available
