Allen-Bradley ControlLogix Reference Manual

Interpret the Attribute Tables
Chapter 3
Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018 129
ID Access
Rule
Attribute B E F P V T Conditional Implementation
612 Set Stopping Time Limit - Y7 Y Y Y F Support in V29
496 Set System Inertia - - R R N
555 Set Torque Integral Time Constant - - N N N
827 Set Torque Lead Lag Filter Bandwidth - - Y Y Y
828 Set Torque Lead Lag Filter Gain - - Y Y Y
554 Set Torque Loop Bandwidth - - Y Y Y
502 Set Torque Low Pass Filter Bandwidth - - Y Y Y
843 Get
Torque Low Pass Filter Bandwidth
Estimate
- - Y Y Y V26/V27
503 Set Torque Notch Filter Frequency - - Y Y Y
841 Get Torque Notch Filter Frequency Estimate - - Y Y Y V26/V27
837 Set Torque Notch Filter High Frequency Limit - - Y Y Y V26/V27
838 Set Torque Notch Filter Low Frequency Limit - - Y Y Y V26/V27
842 Get Torque Notch Filter Magnitude Estimate - - Y Y Y V26/V27
839 Set Torque Notch Filter Tuning Threshold - - Y Y Y V26/V27
591 Set Torque Prove Current - Y5 Y Y Y V26/V27
506 Set Torque Rate Limit - - Y Y Y
507/334 Set Torque Threshold - - Y Y Y
1371 Set Transmission Ratio Input N N N N N DScale
1372 Set Transmission Ratio Output N N N N N DScale
510 Set Undertorque Limit - N Y Y Y
511 Set Undertorque Limit Time - N Y Y Y
464/321 Set Velocity Droop - Y4 Y Y -
465 Set Velocity Error Tolerance - - Y Y -
466 Set Velocity Error Tolerance Time - - Y Y -
366 Get Velocity Fine Command - - Y Y -
467 Set Velocity Integrator Control - - R R - O-Bits
1: Auto-Preset (N)
468 Set Velocity Integrator Preload - - N N -
475 Set Velocity Limit - Bus Overvoltage - - N N - V29
477 Set
Velocity Limit - Bus Overvoltage
Permissive
- - N N - V29
476 Set Velocity Limit - Motor Max - - N N - V29
474/326 Set Velocity Limit - Negative - Y7 Y Y -
473/325 Set Velocity Limit - Positive - Y7 Y Y -
458 Get Velocity Limit Source - - Y Y - V29
471 Set Velocity Lock Tolerance - N Y Y -
469 Set Velocity Low Pass Filter Bandwidth - - Y Y -
790 Set Velocity Negative Feedforward Gain - - Y Y -
470/327 Set Velocity Threshold Y N Y Y Y
608 Set Zero Speed - Y5 Y Y Y V26/V27
