Page #221 background imageLoading...
Page #221 background image
CIP Axis Attributes
Chapter 4
Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018 221
Torque Reference
Usage Access T Data
Type
Default Min Max Semantics of Values
Required - C Get/GSV T REAL - - - % Motor Rated
Commanded torque reference input signal before torque filter section
representing the sum of the Torque Command and Torque Trim signal inputs.
Torque Reference Filtered
Usage Access T Data
Type
Default Min Max Semantics of Values
Required - C Get/GSV T REAL - - - % Motor Rated
Commanded torque reference input signal after torque filter section.
Torque Reference Limited
Usage Access T Data
Type
Default Min Max Semantics of Values
Required - C Get/GSV T REAL - - - % Motor Rated
Commanded torque reference input signal after torque limiter section.
See also
Torque Control Mode on page 20
Torque/Force Control Configuration Attributes on page 211
These are the velocity loop configuration attributes associated with a Motion
Control Axis.
Velocity Offset
Usage Access T Data
Type
Default Min Max Semantics of Values
Required - PV Set/SSV
REAL 0 -maxspd maxspd Velocity Units
The Velocity Offset attribute can be used to provide a velocity bias when
performing velocity control. This value is summed together with the Velocity
Trim value which is sent synchronously to the drive every Coarse Update Period.
Velocity Loop Configuration
Attributes
