Allen-Bradley ControlLogix Reference Manual

Interpret the Attribute Tables
Chapter 3
Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018 181
The following table lists the attributes that are available to a specific drive via
messaging. The P### references in the Conditional Implementation column refer
to the related PowerFlex drive parameter.
ID Attribute K350 K5500 K6500 PF755 E F P V T C/D Conditional Implementation
480 Acceleration Command X X O O O MSG Access Only
1404
+(n-1
)*50
Acceleration Feedback (General Feedback
Signal)
X X X
R R R R E, MSG Access Only
1454 Acceleration Feedback 2 X R R R R E, MSG Access Only
639 Ambient Temperature O O O O MSG Access Only
688 Bus Overvoltage Factory Limit X O O O O MSG Access Only
686
Bus Regulator Overtemperature Factory
Limit
O O O O MSG Access Only
687
Bus Regulator Thermal Overload Factory
Limit
X O O O O MSG Access Only
880 Bus Regulator Reference X O O O O MSG Access Only, P375
689 Bus Undervoltage Factory Limit O O O O MSG Access Only
756 CIP APR Faults C C C C Yes
R-Co CScale; O-Dr DScale; E, MSG Access
Only
757 CIP APR Faults - Mfg C C C C Yes
Vxx; R-Co CScale; O-Dr DScale; E, MSG
Access Only
905 CIP APR Faults - RA C C C C Yes
R-Co CScale; O-Dr DScale; E, MSG Access
Only
660 CIP Axis Alarms - Mfg X X O O O O O Vxx; MSG Access Only
673 CIP Axis Exception Action - Mfg X X X R R R R R MSG Access Only
655 CIP Axis Exceptions X X X R R R R R MSG Access Only
656 CIP Axis Exceptions - Mfg X X X R R R R R Vxx; MSG Access Only
902 CIP Axis Exceptions - RA R R R R R Yes MSG Access Only
658 CIP Axis Faults - Mfg X X X R R R R R Vxx; MSG Access Only
654 CIP Axis I/O Status - Mfg X X X R R R R R Vxx; MSG Access Only
652 CIP Axis Status - Mfg X X X R R R R R Vxx; MSG Access Only
675 CIP Initialization Faults - Mfg X X X R R R R R Yes Vxx; MSG Access Only
677 CIP Start Inhibits - Mfg X X X R R R R Vxx; MSG Access Only
832 Cogging Compensation Table O O O MSG Access Only
768 Command Notch Filter Frequency X O O MSG Access Only
564 Commutation Alignment X X O O O
E; PM Motor only, O- Enum, MSG Access
Only
900
Control Module Overtemperature Factory
Limit
O O O O O MSG Access Only
710 Control Power-up Time O O O O MSG Access Only
693 Converter Ground Current Factory Limit O O O O MSG Access Only
684 Converter Overtemperature Factory Limit O O O O MSG Access Only
901
Converter Precharge Overload Factory
Limit
O O O O MSG Access Only
723 Converter Rated Output Current X X - O O O O Yes MSG Access Only
MSG Instruction Access Only
Attributes

Allen-Bradley ControlLogix Specifications

General

Communication	EtherNet/IP, ControlNet, DeviceNet, DH+
I/O Capacity	Up to 128, 000 I/O points (varies by configuration)
Redundancy	Supported (with specific modules)
Programming Software	Rockwell Automation Studio 5000 Logix Designer
Operating Temperature	0°C to 60°C (32°F to 140°F)
Programming Languages	Ladder Logic, Function Block Diagram, Structured Text, Sequential Function Chart
Modularity	Yes
Certifications	UL, CE
Processor Type	Multiple options available, including standard, safety, and extreme environment processors
Power Supply	Multiple options available, including standard and redundant power supplies with various voltage ranges (e.g., 24V DC, 120/240V AC)
