Allen-Bradley ControlLogix Reference Manual

CIP Axis Attributes
Chapter 4
Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018 469
Bit Object CIP Axis Alarm Name
5 Feedback Battery Loss Alarm
6 Feedback Battery Low Alarm
7 Feedback Incremental Count Error Alarm
10 Control Module Overtemperature FL Alarm
12 Converter Pre Charge Overload FL Alarm
14 Excessive Current Feedback Offset Alarm
15 Regenerative Power Supply Alarm
16 PWM Frequency Reduced Alarm
17 Current Limit Reduced Alarm
18 Torque Prove Alarm
19 Decel Override Alarm
20 Preventative Maintenance Alarm
21 Motor Test Alarm
22 Hardware Configuration Alarm
23 Firmware Change Alarm
24 Converter Pre-Charge Input Deactivated Alarm
25 DC Common Bus Alarm
26 Runtime Error Alarm
27 Backplane Communication Error Alarm
28 Safety Module Communication Error Alarm
63 Product Specific Alarm
See also
Rockwell Automation Specific Exceptions on page 465
Rockwell Automation Specific CIP Axis Fault Names on page 467
Rockwell Automation Specific Initialization Faults on page 296
Rockwell Automation Specific Start Inhibits on page 455

Allen-Bradley ControlLogix Specifications

General

Communication	EtherNet/IP, ControlNet, DeviceNet, DH+
I/O Capacity	Up to 128, 000 I/O points (varies by configuration)
Redundancy	Supported (with specific modules)
Programming Software	Rockwell Automation Studio 5000 Logix Designer
Operating Temperature	0°C to 60°C (32°F to 140°F)
Programming Languages	Ladder Logic, Function Block Diagram, Structured Text, Sequential Function Chart
Modularity	Yes
Certifications	UL, CE
Processor Type	Multiple options available, including standard, safety, and extreme environment processors
Power Supply	Multiple options available, including standard and redundant power supplies with various voltage ranges (e.g., 24V DC, 120/240V AC)
