Allen-Bradley ControlLogix Reference Manual

CIP Axis Attributes
Chapter 4
Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018 205
Maximum Voltage
Usage Access Data
Type
Default Min Max Semantics of Values
Required - F Set/SSV REAL 460
FD
0
Volts (RMS)
The Maximum Voltage attribute sets the highest phase-to-phase voltage the drive
device can output.
Maximum Frequency
Usage Access Data
Type
Default Min Max Semantics of Values
Required - F Set/SSV REAL 130
FD
0
Hertz
The Maximum Frequency attribute sets the highest frequency the drive device can
output.
Break Voltage
Usage Access Data
Type
Default Min Max Semantics of Values
Required - F Set/SSV REAL 230
FD
0
Volts (RMS)
The Break Voltage attribute sets the phase-to-phase output voltage of the drive
device at the Break Frequency where boost ends.
Only applicable in Basic V/Hz mode.
Break Frequency
Usage Access Data
Type
Default Min Max Semantics of Values
Required - F Set/SSV REAL 30
FD
0
Hertz
The Break Frequency attribute sets the output frequency of the drive device at the
Break Voltage where boost ends.
Only applicable in Basic V/Hz mode.

Allen-Bradley ControlLogix Specifications

General

Communication	EtherNet/IP, ControlNet, DeviceNet, DH+
I/O Capacity	Up to 128, 000 I/O points (varies by configuration)
Redundancy	Supported (with specific modules)
Programming Software	Rockwell Automation Studio 5000 Logix Designer
Operating Temperature	0°C to 60°C (32°F to 140°F)
Programming Languages	Ladder Logic, Function Block Diagram, Structured Text, Sequential Function Chart
Modularity	Yes
Certifications	UL, CE
Processor Type	Multiple options available, including standard, safety, and extreme environment processors
Power Supply	Multiple options available, including standard and redundant power supplies with various voltage ranges (e.g., 24V DC, 120/240V AC)
