462 Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018
This table lists the resulting Fault names associated with the Standard Exception
conditions.
Standard CIP Axis Fault Names
Bit Object CIP Axis Fault Name
0 --Reserved--
1 Motor Overcurrent Fault
2 Motor Commutation Fault
3 Motor Overspeed FL Fault
4 Motor Overspeed UL Fault
5 Motor Overtemperature FL Fault
6 --Reserved--
7 Motor Thermal Overload FL Fault
8 Motor Thermal Overload UL Fault
9 Motor Phase Loss Fault
10 Inverter Overcurrent Fault
11 Inverter Overtemperature FL Fault
12 --Reserved--
13 Inverter Thermal Overload FL Fault
14 Inverter Thermal Overload UL Fault
15 Converter Overcurrent Fault
16 Converter Ground Current FL Fault
17 Converter Ground Current UL Fault
18 Converter Overtemperature FL Fault
19 Converter Overtemperature UL Fault
20 Converter Thermal Overload FL Fault
21 Converter Thermal Overload UL Fault
22 Converter AC Power Loss Fault
23 Converter AC Single Phase Loss Fault
24 Converter AC Phase Short Fault
25 Converter Pre Charge Fault
26 --Reserved--
27 Bus Regulator Overtemperature FL Fault
28 Bus Regulator Overtemperature UL Fault
29 Bus Regulator Thermal Overload FL Fault
30 Bus Regulator Thermal Overload UL Fault
31 Bus Regulator Fault
32 Bus Capacitor Module Fault
