Allen-Bradley ControlLogix Reference Manual

Chapter 4
CIP Axis Attributes
464 Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018
2 Motor Commutation Alarm
3 Motor Overspeed FL Alarm
4 Motor Overspeed UL Alarm
5 Motor Overtemperature FL Alarm
6 --Reserved--
7 Motor Thermal Overload FL Alarm
8 Motor Thermal Overload UL Alarm
9 Motor Phase Loss Alarm
10 Inverter Overcurrent Alarm
11 Inverter Overtemperature FL Alarm
12 --Reserved--
13 Inverter Thermal Overload FL Alarm
14 Inverter Thermal Overload UL Alarm
15 Converter Overcurrent Alarm
16 Converter Ground Current FL Alarm
17 Converter Ground Current UL Alarm
18 Converter Overtemperature FL Alarm
19 Converter Overtemperature UL Alarm
20 Converter Thermal Overload FL Alarm
21 Converter Thermal Overload UL Alarm
22 Converter AC Power Loss Alarm
23 Converter AC Single Phase Loss Alarm
24 Converter AC Phase Short Alarm
25 Converter Pre Charge Alarm
26 --Reserved--
27 Bus Regulator Overtemperature FL Alarm
28 Bus Regulator Overtemperature UL Alarm
29 Bus Regulator Thermal Overload FL Alarm
30 Bus Regulator Thermal Overload UL Alarm
31 Bus Regulator Alarm
32 Bus Capacitator Module Alarm
33 Bus Undervoltage FL Alarm
34 Bus Undervoltage UL Alarm
35 Bus Overvoltage FL Alarm
36 Bus Overvoltage UL Alarm
37 Bus Power Loss Alarm
38 Bus Power Blown Fuse Alarm
39 Bus Power Leakage Alarm
40 Bus Power Sharing Alarm
41 Feedback Signal Noise FL Alarm
42 Feedback Signal Noise UL Alarm

Allen-Bradley ControlLogix Specifications

General

Communication	EtherNet/IP, ControlNet, DeviceNet, DH+
I/O Capacity	Up to 128, 000 I/O points (varies by configuration)
Redundancy	Supported (with specific modules)
Programming Software	Rockwell Automation Studio 5000 Logix Designer
Operating Temperature	0°C to 60°C (32°F to 140°F)
Programming Languages	Ladder Logic, Function Block Diagram, Structured Text, Sequential Function Chart
Modularity	Yes
Certifications	UL, CE
Processor Type	Multiple options available, including standard, safety, and extreme environment processors
Power Supply	Multiple options available, including standard and redundant power supplies with various voltage ranges (e.g., 24V DC, 120/240V AC)
