Rockwell Automation Publication 2097-UM002D-EN-P - April 2017 119
Troubleshoot the Kinetix 350 Drive Chapter 7
Status Indicators
Table 52 - Drive Status Indicator
Table 53 - Axis Status Indicator
Status Description
Off No power. Apply power.
Alternating green/red Self-test (power-up diagnostics). Wait for steady green.
Flashing green Standby (device not configured). Wait for steady green.
Steady green Normal operation, no faults.
Flashing red Minor fault (recoverable). See four-digit fault message.
Steady red Major fault (non-recoverable). See four-digit fault message.
Status Description
Off Off
Flash red/green Self test
Off Initialization - bus not up
Flashing green Initialization - bus up
Off Shutdown - bus not up
Flashing amber
(1)
(1) The axis and the drive define minor fault conditions. While a minor fault does not affect the drive status indicator, it does affect
the axis status indicator. When a minor fault condition is detected, a normally solid-green status indicator indication changes to
alternating red-green-red-green, a normally flashing green status indicator indication changes to alternating red-off-green-off,
and a normally flashing amber indications changes to red-off-amber-off.
Shutdown - bus up
Off Pre-charge - bus not up
Flashing amber
(1)
Start inhibit
Flashing green
(1)
(2)
(2) The drive also defines alarm conditions. When an alarm condition is detected, a normally solid-green status indicator indication
changes to alternating amber-green-amber green while a normally flashing green status indicator indication changes to
alternating amber-off-green-off.
Stopped
Solid green
(1)
(2)
Stopping
Starting
Running
Tes ti ng
Flashing red
Aborting
Major faulted
Solid red
Aborting
Major faulted
