Allen-Bradley LOGIX 5000 User Manual

Process Control Instructions
Chapter 1
Rockwell Automation Publication 1756-RM006K-EN-P - November 2018 161
ProgCV2AutoReq BOOL Program-Auto mode request for CV2.
Set TRUE by the user program to
request Auto mode.
If value of CV2HandFB < 0 or > 100,
set unique Status bit and limit value
used for CV2.
Default = FALSE
ProgCV3AutoReq BOOL Program-Auto mode request for CV3.
Set TRUE by the user program to
request Auto mode.
If value of CV3HandFB < 0 or > 100,
set unique Status bit and limit value
used for CV3.
Default = FALSE
ProgCV1ManualReq BOOL Program-Manual mode request for
CV1.
Set TRUE by the user program to
request Manual mode.
If value of CV1HandFB < 0 or > 100,
set unique Status bit and limit value
used for CV1.
Default = FALSE
ProgCV2ManualReq BOOL Program-Manual mode request for
CV2.
Set TRUE by the user program to
request Manual mode.
If value of CV2HandFB < 0 or > 100,
set unique Status bit and limit value
used for CV2.
Default = FALSE
ProgCV3ManualReq BOOL Program-Manual mode request for
CV3.
Set TRUE by the user program to
request Manual mode.
If value of CV3HandFB < 0 or > 100,
set unique Status bit and limit value
used for CV3.
Default = FALSE
ProgCV1OverrideReq BOOL Program-Override mode request for
CV1.
Set TRUE by the user program to
request Override mode.
If value of CV1HandFB < 0 or > 100,
set unique Status bit and limit value
used for CV1.
Default = FALSE
ProgCV2OverrideReq BOOL Program-Override mode request for
CV2.
Set TRUE by the user program to
request Override mode.
If value of CV2HandFB < 0 or > 100,
set unique Status bit and limit value
used for CV2.
Default = FALSE
ProgCV3OverrideReq BOOL Program-Override mode request for
CV3.
Set TRUE by the user program to
request Override mode.
If value of CV3HandFB < 0 or > 100,
set unique Status bit and limit value
used for CV3.
Default = FALSE
