Process Control Instructions
Chapter 1
Rockwell Automation Publication 1756-RM006K-EN-P - November 2018 221
Input Parameters Data
Type
Description Values
CV2PV1ResponseSp
eed
DINT Desired speed of closed loop response for CV2
PV1.
• Slow response: ResponseSpeed=0
• Medium response: ResponseSpeed=1
• Fast response: ResponseSpeed=2
If ResponseSpeed is less than 0, Slow response is
used. If ResponseSpeed is greater than 2, Fast
response is used.
Range: 0…2
Default=1
CV3PV1ResponseSp
eed
DINT Desired speed of closed loop response for CV3
PV1.
• Slow response: ResponseSpeed=0
• Medium response: ResponseSpeed=1
• Fast response: ResponseSpeed=2
If ResponseSpeed is less than 0, Slow response is
used. If ResponseSpeed is greater than 2, Fast
response is used.
Range: 0 through 2
Default=1
CV1PV2ResponseSp
eed
DINT Desired speed of closed loop response for CV1
PV2.
• Slow response: ResponseSpeed=0
• Medium response: ResponseSpeed=1
• Fast response: ResponseSpeed=2
If ResponseSpeed is less than 0, Slow response is
used. If ResponseSpeed is greater than 2, Fast
response is used.
Range: 0 through 2
Default=1
CV2PV2ResponseSp
eed
DINT Desired speed of closed loop response for CV2
PV2.
• Slow response: ResponseSpeed=0
• Medium response: ResponseSpeed=1
• Fast response: ResponseSpeed=2
If ResponseSpeed is less than 0, Slow response is
used. If ResponseSpeed is greater than 2, Fast
response is used.
Range: 0 through 2
Default=1
CV3PV2ResponseSp
eed
DINT Desired speed of closed loop response for CV3
PV2.
• Slow response: ResponseSpeed=0
• Medium response: ResponseSpeed=1
• Fast response: ResponseSpeed=2
If ResponseSpeed is less than 0, Slow response is
used. If ResponseSpeed is greater than 2, Fast
response is used.
Range: 0 through 2
Default=1
CV1PV1ModelInit BOOL Internal model initialization switch for CV1 - PV1.
Refer to Function Block Attributes.
Default = FALSE
CV2PV1ModelInit BOOL Internal model initialization switch for CV2 - PV1.
Refer to Function Block Attributes.
Default = FALSE
CV3PV1ModelInit BOOL Internal model initialization switch for CV3 - PV1.
Refer to Function Block Attributes.
Default = FALSE
