Chapter 7
Equipment Phase Instructions
438 Rockwell Automation Publication 1756-RM006K-EN-P - November 2018
Download the low limit of an input parameter Download Batch Data DINT[0] 6
The input parameter tag stores
the low limit.
Download the high limit of an input
parameter
Download Batch Data DINT[0] 7
The input parameter tag stores
the high limit.
Download data about the container currently
in use
Download Material
Manager Data Container In
Use
DINT[0] 1
DINT[1] Attribute ID (specify the single
attribute).
DINT[2] Phase parameter ID (specify the
parameter tag to download the
value to)
Download data about the current material
inside the container currently in use
Download Material
Manager Data Container In
Use
DINT[0] 2
DINT[1] Attribute ID (specify the single
attribute).
DINT[2] Phase parameter ID (specify the
parameter tag to which to
download the value)
Download data about the current lot inside
the container currently in use
Download Material
Manager Data Container In
Use
DINT[0] 3
DINT[1] Attribute ID (specify the single
attribute).
DINT[2] Phase parameter ID (specify the
parameter tag to which to
download the value)
Upload data about the container currently in
use
Upload Material Manager
Data Container In Use
DINT[0] 1
DINT[1] Attribute ID (specify the single
attribute).
DINT[2] Phase parameter ID (specify the
parameter tag from which to
upload the value)
Upload data about the current material inside
the container currently in use
Upload Material Manager
Data Container In Use
DINT[0] 2
DINT[1] Attribute ID (specify the single
attribute).
DINT[2] Phase parameter ID (specify the
parameter tag from which to
upload the value)
Upload data about the current lot inside the
container currently in use
Upload Material Manager
Data Container In Use
DINT[0] 3
DINT[1] Attribute ID (specify the single
attribute).
DINT[2] Phase parameter ID (specify the
parameter)
Download the current binding's container
priority
Download Container
Binding Priority
DINT[0] parameter ID in which to store
the value
