Publication 1763-RM001C-EN-P - October 2009
Using the High-Speed Counter and Programmable Limit Switch 109
HSC Mode 2 - Counter with External Direction
Blank cells = don’t care, ⇑ = rising edge, ⇓ = falling edge
HSC Mode 3 - Counter with External Direction, Reset, and Hold
Blank cells = don’t care, ⇑ = rising edge, ⇓ = falling edge
HSC Mode 2 Examples
Input Terminals I1:0.0/0 (HSC0) I1:0.0/1 (HSC0) I1:0.0/2 (HSC0) I1:0.0/3 (HSC0) CE Bit Comments
Function Count Direction Not Used Not Used
Example 1 ⇑ off
(0)
on (1) HSC Accumulator + 1 count
Example 2 ⇑ on
(1)
on (1) HSC Accumulator - 1 count
Example3 off (0) Hold accumulator value
TIP
Inputs I1:0.0/0 through I1:0.0/3 are available for use as
inputs to other functions regardless of the HSC being
used.
HSC Mode 3 Examples
Input Terminals I1:0.0/0 (HSC0) I1:0.0/1 (HSC0) I1:0.0/2 (HSC0) I1:0.0/3 (HSC0) CE Bit Comments
Function Count Direction Reset Hold
Example 1 ⇑ off
(0)
on
(1)
⇓ off
(0)
off
(0)
on (1) HSC Accumulator + 1 count
Example 2 ⇑ on
(1)
on
(1)
⇓ off
(0)
off
(0)
on (1) HSC Accumulator - 1 count
Example3 on
(1)
⇓ off
(0)
on
(1)
Hold accumulator value
Example 4 on
(1)
⇓ off
(0)
off (0) Hold accumulator value
Example 5 on
(1)
⇓ off
(0)
on
(1)
⇓ off
(0)
Hold accumulator value
Example 6 ⇑ Clear accumulator (=0)
TIP
Inputs I1:0.0/0 through I1:0.0/3 are available for use as
inputs to other functions regardless of the HSC being
used.
