Publication 1763-RM001C-EN-P - October 2009
50 Function Files
Overview
Function Files are one of the three primary file structures within the
MicroLogix 1100 controller (Program Files and Data Files are the others).
Function Files provide an efficient and logical interface to controller
resources. Controller resources are resident (permanent) features such as
the Real-Time Clock and High-Speed Counter. The features are available
to the control program through either instructions that are dedicated to a
specific function file, or via standard instructions such as MOV and ADD.
The Function File types are:
Function Files
File Name File
Identifier
File Description
High-Speed Counter HSC This file type is associated with the High-Speed Counter function. See Using the
High-Speed Counter and Programmable Limit Switch on page 89 for more information.
Pulse Train Output PTO This file type is associated with the Pulse Train Output Instruction. See Pulse Train Outputs
(PTO) Function File on page 133 for more information.
Pulse Width Modulation PWM This file type is associated with the Pulse Width Modulation instruction. See Pulse Width
Modulation (PWM) Function File on page 150 for more information.
Selectable Timed Interrupt STI This file type is associated with the Selectable Timed Interrupt function. See Using the
Selectable Timed Interrupt (STI) Function File on page 268 for more information.
Event Input Interrupt EII This file type is associated with the Event Input Interrupt instruction. See Using the Event
Input Interrupt (EII) Function File on page 272 for more information.
Real-Time Clock RTC This file type is associated with the Real-Time Clock (time of day) function. See Real-Time
Clock Function File on page 51 for more information.
Memory Module
Information
MMI This file type contains information about the Memory Module. See Memory Module
Information Function File on page 54 for more information.
Base Hardware Information BHI This file type contains information about the controller’s hardware. See Base Hardware
Information Function File on page 56 for the file structure.
Communications Status
File
CS This file type contains information about the Communications with the controller. See
Communications Status File on page 57 for the file structure.
I/O Status File IOS This file type contains information about the controller I/O. See Input/Output Status File on
page 79 for the file structure.
Ethernet Status File ES The file type contains information about the Ethernet Communications with the controller.
LCD Information File LCD This file type is associated with the LCD screen, keypads, and trimpot.
