Allen-Bradley MicroLogix 1100 Instruction Set Reference Manual

159 Publication 1763-RM001C-EN-P - October 2009
Chapter 6
Relay-Type (Bit) Instructions
Use relay-type (bit) instructions to monitor and/or control bits in a data
file or function file, such as input bits or timer control-word bits. The
following instructions are described in this chapter:
These instructions operate on a single bit of data. During operation, the
processor may set or reset the bit, based on logical continuity of ladder
rungs. You can address a bit as many times as your program requires.
XIC - Examine if Closed
XIO - Examine if Open
Instruction Type: input
Use the XIC instruction to determine if the addressed bit is on. Use the
XIO instruction to determine if the addressed bit is off.
Instruction Used To: Page
XIC - Examine if Closed Examine a bit for an ON condition 159
XIO - Examine if Open Examine a bit for an OFF condition 159
OTE - Output Enable Turn ON or OFF a bit (non-retentive) 161
OTL - Output Latch Latch a bit ON (retentive) 162
OTU - Output Unlatch Unlatch a bit OFF (retentive) 162
ONS - One Shot Detect an OFF to ON transition 163
OSR - One Shot Rising Detect an OFF to ON transition 164
OSF - One Shot Falling Detect an ON to OFF transition 164
B3:0
0
B3:0
0
Execution Time for the XIC Instruction
Controller When Instruction Is:
True False
MicroLogix 1100 1.5 μs 1.45 μs
Execution Time for the XIO Instruction
Controller When Instruction Is:
True False
MicroLogix 1100 1.5 μs1.5 μs
efesotomasyon.com - Allen Bradley,Rockwell,plc,servo,drive

Allen-Bradley MicroLogix 1100 Specifications

General

Processor	32-bit
Programming Software	RSLogix 500
Mounting	DIN rail or panel mount
Power Supply	24V DC
Type	Compact PLC
Digital Inputs	12
Digital Outputs	8
Analog Inputs	4 (depending on model)
Analog Outputs	Optional with expansion module
Programming Language	Ladder Logic
Operating Temperature	0 to 55 °C (32 to 131 °F)
Series	MicroLogix
