170 Timer and Counter Instructions
Timer Accuracy
Timer accuracy refers to the length of time between the moment a timer
instruction is enabled and the moment the timed interval is complete.
If your program scan can exceed 2.5 seconds, repeat the timer instruction
on a different rung (identical logic) in a different area of the ladder code
so that the rung is scanned within these limits.
Repeating Timer Instructions
Using the enable bit (EN) of a timer is an easy way to repeat its complex
conditional logic at another rung in your ladder program.
Timer Accuracy
Time Base Accuracy
0.001 seconds -0.001 to 0.00
0.01 seconds -0.01 to 0.00
1.00 seconds -1.00 to 0.00
TIP
Timing could be inaccurate if Jump (JMP), Label (LBL),
Jump to Subroutine (JSR), or Subroutine (SBR)
instructions skip over the rung containing a timer
instruction while the timer is timing. If the skip duration
is within 2.5 seconds, no time is lost; if the skip duration
exceeds 2.5 seconds, an undetectable timing error
occurs. When using subroutines, a timer must be
scanned at least every 2.5 seconds to prevent a timing
error.
