Allen-Bradley MicroLogix 1100 Instruction Set Reference Manual

Publication 1763-RM001C-EN-P - October 2009
338 ASCII Instructions
10 0x0A The unload bit (UL) is set, stopping instruction
execution.
None required.
11 0x0B The requested number of characters for the ASCII
read was too large or negative.
Enter a valid string length and retry operation.
12 0x0C The length of the Source string is invalid (either a
negative number or a number greater than 82).
Enter a valid string length and retry operation.
13 0x0D The requested length in the Control field is invalid
(either a negative number or a number greater than
82).
Enter a valid length and retry operation.
14 0x0E Execution of an ACL instruction caused this
instruction to abort.
None required.
15 0x0F Communications channel configuration was changed
while instruction was in progress.
None required.
Error Code Description Recommended Action
decimal hexadecimal
