Allen-Bradley MicroLogix 1100 Instruction Set Reference Manual

Publication 1763-RM001C-EN-P - October 2009
LCD - LCD Information 451
Target Integer File Number (TIF)
Target Integer File Number (TIF) specifies the integer file to monitor on
the LCD. When a valid bit file is specified, the Monitoring and Integer
menus are available. Up to the first 48 words of the specified integer file
can be monitored and modified. For more information, refer to Using
Trim Pots described in the MicroLogix 1100 Programmable Controllers
User Manual, publication 1763-UM001.
Jog data update Mode set (JOG)
Jog data update Mode set (JOG) determines how the value changes are
applied when you press the Up and Down keys to change the data value
for a trim pot. When this bit is set (1), the changes are applied
immediately whenever you press the Up and Down keys. When it is clear
(0), the changes are applied only when you press the OK key after you
have changed the value using the Up and Down keys.
There are three ways to change JOG bit:
• Editing the LCD Function File with your RSLogix 500 programming
tool
• Manipulating this bit using a ladder program
• Using the Advance Set and KeyIn Mode menus on the LCD
Trimpot 0 Data (TMIN – TMAX) (POT0),
Trimpot 1 Data (TMIN – TMAX) (POT1)
Feature Address Data Format Type User Program
Access
TIF - Target Integer File
Number
LCD:0.TIF word (INT) control read-only
Feature Address Data Format Type User Program
Access
JOG - Jog data update
Mode set
LCD:0/JOG binary (bit) control read/write
Feature Address Data Format Type User Program
Access
POT0 - Trimpot 0 Data
(TMIN – TMAX)
LCD:0.POT0 word (INT) status read-only
POT1 - Trimpot 1 Data
(TMIN – TMAX)
LCD:0.POT1 word (INT) status read-only
