Allen-Bradley MicroLogix 1100 Instruction Set Reference Manual

Publication 1763-RM001C-EN-P - October 2009
460 MicroLogix 1100 Memory Usage and Instruction Execution Time
MicroLogix 1100 Indirect Addressing
The following sections describe how indirect addressing affects the
execution time of instructions in the MicroLogix 1100 processor. The
timing for an indirect address is affected by the form of the indirect
address.
For the address forms in the following table, you can interchange the
following file types:
• Input (I) and Output (O)
• Bit (B), Integer (N)
• Timer (T), Counter (C), and Control (R)
Service Communications SVC channel 0 94.1
μs
channel 1 87.0
μs
both 203.1 μs
0.87 0.8 None None None
Swap SWP 9.15 + 0.43/
word
0.87 1.4 None None None
Temporary End TND 1.00 0.78 0.2 None None None
Convert to BCD TOD 29.31 0.87 1.4 None None None
Off-Delay Timer TOF 2.68 2.68 (DN=1),
4.03 (DN=0)
0.8 None None None
On-Delay Timer TON 2.71 (DN=1),
4.06 (DN=0)
2.59 0.8 None None None
User Interrupt Disable UID 9.28 0.87 0.8 None None None
User Interrupt Enable UIE 9.28 0.87 0.8 None None None
User Interrupt Flush UIF 23.78 0.87 0.8 None None None
Examine if Closed XIC 1.5 1.45 0.8 None None None
Examine if Open XIO 1.5 1.50 0.8 None None None
Exclusive Or XOR 13.09 0.87 2.0 13.31 0.87
Start Of Rung SOR 1.10 1.10 0.6 None None None
End END 0.10 0.10 0.2 None None None
End Of Rung EOR 0.00 0.00 0.0 None None None
MicroLogix 1100 Controllers -
Memory Usage and Instruction Execution Time for Programming Instructions
Programming Instruction Instruction
Mnemonic
Word Long Word
Execution Time in µs Memory
Usage in
Words
Execution Time in µs Memory
Usage in
Words
True False True False
