Allen-Bradley MicroLogix 1100 Instruction Set Reference Manual

Publication 1763-RM001C-EN-P - October 2009
System Status File 469
Forces Enabled
This bit is always set (1) by the controller to indicate that forces are
enabled.
Forces Installed
This bit is set (1) by the controller to indicate that 1 or more inputs or
outputs are forced. When this bit is clear, a force condition is not present
within the controller.
Address Data Format Range Type User Program Access
S:1/5 binary 1 status read only
Address Data Format Range Type User Program Access
S:1/6 binary 0 or 1 status read only
